Nuie Thermostatic Square Shower Bar Valve (1 size, Chrome)
Couldn't load pickup availability
Direct Bank Transfers available for orders over £500.
Finance Options with PayPal & Klarna
Need Any Help? Speak to one of our Sales team between 9am & 5pm - seven days a week for expert advice.
The Nuie Bar Showers Thermostatic Bar Valve offers precise temperature control, even with fluctuating water pressure. Its full thermal protection prevents scalding, and it shuts down in case of hot or cold water failure. Made from high-quality brass & ABS, this valve is ideal for unvented mains pressure systems and shower pumps. Elevate your shower experience.
Specifications
| Range: |
Shower Valves
|
| Depth (mm): | 40 |
| Height (mm): | 32 |
| Width (mm): | 257 |
| Valve/Cartirdge Type: |
1/4 Turn |
| Flow Rate 0.5Bar l/m: | 9 |
| Flow Rate 1Bar l/m: | 14 |
| Flow Rate 2Bar l/m: | 21 |
| Flow Rate 3Bar l/m: | 26 |
| TMV3 Approved: |
No |
| TMV2 Approved: |
No |
| Minimum Operating Pressure (Bar): |
0.5 |
| WRAS Approved: | No |
| Mount Type: |
Surface/Wall |
| Guarantee: | 5 years |
To view the Technical Datasheet for this product, click HERE
To view the Technical Fittings instructions for this product, click HERE
- Thermostatically controlled
- Bottom outlet
- Thermostatic control to +/- 2 degrees even if the water pressure fluctuates
- Full thermal protection to prevent scalding in the event of hot or cold water shut off
- In the event of hot or cold water failure the valve will shut down as per the relevant standard
- Suitable for unvented mains pressure systems
- Suitable for shower pumps
- Manufactured from high quality brass & ABS
