Hudson Reed Tec Crosshead Bath Filler (1 size, 3 colours)
Couldn't load pickup availability
Direct Bank Transfers available for orders over £500.
Finance Options with PayPal & Klarna
Need Any Help? Speak to one of our Sales team between 9am & 5pm - seven days a week for expert advice.
Dare to fill your bath with the timeless symmetry of the Hudson Reed Tec Crosshead Bath Filler. With a swivel spout, ceramic disc technology for smooth operation, and high quality brass internals, this WRAS approved bath filler makes luxury a standard. Available in 3 bold colours to fit any daring style.
Specifications
| Guarantee (Years): | 3 |
| Range: |
Tec Cross Taps
|
| Mount Type: |
Deck |
| Minimum Operating Pressure (Bar): |
0.2 Bar |
| Flow Rate 0.1Bar l/m: | 8 |
|
Flow Rate 0.5Bar l/m: |
29 |
| Flow Rate 1Bar l/m: | 40 |
| Flow Rate 2Bar l/m: | 48 |
| Tap Holes Required: |
2
|
| Tap Spout Projection: |
115 |
| Shipping Load Type: |
Standard Parcel
|
| Pipe Size: |
22
|
| Product Depth (mm): | 50 |
| Product Height (mm): | 319 |
| Product Width (mm): | 230 |
| Valve/Cartridge Type: |
1/4 Turn Ceramic Disc
|
| WRAS Approved: | Yes |
| WRAS Approval Number: |
2204060 |
To view the Technical Datasheet for this product Chrome, click HERE
To view the Technical Datasheet for this product Matt Black, click HERE
To view the Technical Datasheet for this product Brushed Brass, click HERE
To view the Fitting Instructions for this product, click HERE
