Nuie Square Thermostatic Bar Valve & Shower Kit (1 size, 3 colours)
Couldn't load pickup availability
Direct Bank Transfers available for orders over £500.
Finance Options with PayPal & Klarna
Need Any Help? Speak to one of our Sales team between 9am & 5pm - seven days a week for expert advice.
Indulge in the ultimate luxury shower experience with our Nuie Square Thermostatic Bar Shower Kit. With precise temperature control and full thermal protection, enjoy a refreshing and safe shower every time. Crafted from high-quality brass and ABS, this shower kit is suitable for all types of water systems. Elevate your shower routine today with our elegant and sophisticated shower kit.
Specifications
| Range: |
Shower Sets
|
| Flow Rate at 0.5 Bar (L/min): |
3
|
| Flow Rate at 1 Bar (L/min): |
5
|
| Flow Rate at 2 Bar (L/min): |
9
|
| Flow Rate at 3 Bar (L/min): |
12
|
| Pipe Size: | 15 |
| Depth (mm): | 465 |
| Height (mm): | 1200 |
| Width (mm): | 200 |
| Mount Type: |
Surface/Wall |
| Minimum Operating Pressure (Bar): |
1 |
| TMV3 Approved: |
No |
| TMV2 Approved: |
No |
| TMV2 Approval Number: | 2310177 |
| Valve/Cartridge Type: |
1/4 Turn |
| WRAS Approved: | 2307019 |
| Guarantee: | 3 years |
To view the Technical Datasheet for this product, click HERE
To view the Technical Datasheet for this product, click HERE
To view the Technical Datasheet for this product, click HERE
To view the Technical Fittings instructions for this product, click HERE
- The perfect solution to multi-option showering.
- Thermostatically controlled.
- Square shower head.
- Square handset.
- Thermostatic control to +/- 2 degrees even if the water pressure fluctuates.
- Full thermal protection to prevent scalding in the event of hot or cold water shut off.
- In the event of hot or cold water failure the valve will shut down as per the relevant standard.
- Suitable for high pressure water systems.
- Suitable for unvented mains pressure systems.
- Suitable for shower pumps.
- Manufactured from high quality brass & ABS.
