Nuie Windon Triple Thermostatic Shower Valve (1 size, Chrome)
Couldn't load pickup availability
Direct Bank Transfers available for orders over £500.
Finance Options with PayPal & Klarna
Need Any Help? Speak to one of our Sales team between 9am & 5pm - seven days a week for expert advice.
The Nuie Windon Triple Thermostatic Shower Valve offers a modern and sleek design with versatile installation options. Its precise flow control and thermal protection ensure a safe and comfortable shower experience. With resistance to calcium build-up and compatibility with all water systems, this valve provides excellent flow rates and easy re-plumbing.
Specifications
| Range: |
Windon
|
| Depth (mm): | 135 |
| Height (mm): | 280 |
| Width (mm): | 120 |
| Valve/Cartridge Type: |
1/4 Turn |
| Flow Rate at 0.1 Bar (L/min): |
5.5 |
| Flow Rate 0.5Bar l/m: | 14 |
| Flow Rate 1Bar l/m: | 20 |
| Flow Rate 2Bar l/m: | 29 |
| Flow Rate 3Bar l/m: | 44 |
| TMV3 Approved: |
No |
| TMV2 Approved: |
No |
| Minimum Operating Pressure (Bar): |
0.1 |
| WRAS Approved: | 250602040 |
| Mount Type: |
Concealed |
| Guarantee: | 5 years |
To view the Technical Datasheet for this product, click HERE
To view the Technical Fittings instructions for this product, click HERE
- Minimalist sleek design
- Can be fitted vertically or horizontally
- Accurate flow control
- Thermostatic control to +/- 2 degrees even if the water pressure fluctuates
- Full thermal protection to prevent scalding in the event of hot or cold water shut off
- In the event of hot or cold water failure the valve will shut down as per the relevant standard
- The unique cartridge is highly resistant to calcium build up - even in hard water areas
- Our valves are suitable for use with all systems: gravity fed pumped unvented high pressure or fully modulated combi-boilers
- Excellent flow rates - even at low pressure
- The cartridge is fully reversible meaning if hot and cold supplies are the wrong way round it doesn't need re-plumbing
- Simply remove the cartridge turn 180° and replace
- Manufactured from high quality brass & ABS
